Plain Elevation Bricks
Slim concrete brick tile for facades, applied with adhesive.
✦ KEY ARCHITECTURAL HIGHLIGHTS
- Only 15 mm thick — no load added to the structure
- Fixes with tile adhesive on existing walls
- Clean lines for modular and stack bond patterns
- Colour through the body, not a surface coat
⚡ LIVE ESTIMATORProject Quantity & Freight Weight
Enter elevation wall area to calculate exact piece count & logistics tonnageSQ. FT.
Pieces Required
387,096pcs
Est. Weight
232.26 MT (232,258 kg)
ARCHITECTURAL SPECIFICATION & OVERVIEW
About Plain Elevation Bricks
Plain Elevation Bricks is part of the Elevation & Cladding Bricks range manufactured by Kamad Infratech.
A 15 mm thick concrete cladding tile in a long brick format. Because it is a tile and not a brick, it goes onto an existing wall with adhesive — no extra foundation, no wall thickness lost.
The plain face suits tight modular patterns, stack bond and vertical fins. Architects use it where they want the brick language without the brick weight.
Enterprise GradeEngineered for large-scale architectural projects
Climate ResilientTested for Indian climate extremes — heat, rain, humidity
Factory PrecisionBatch-controlled production with anti-efflorescence mix design
Sustainable MaterialEco-conscious production with minimal carbon footprint
Plain Elevation Bricks — Technical Specifications
Technical Specifications & Dimensional Matrix
Available Sizes & Dimensions
8 in × 3 in × 15 mm thick
Colours & Surface Finishes
WhiteGreyTerracottaBlack
Material Composition
Pigmented concrete
Minimum Order Quantity (MOQ)
200 sq.ft.
Plain Elevation Bricks — Applications and Usage Areas
Primary Applications
- Exterior Building Facades & Solar Shading Screens
- Ventilated Boundary Walls & Perimeter Enclosures
- Interior Feature Partition Walls & Atrium Screens
- Balcony & Terrace Privacy Screening
Usage Areas & Project Types
- Luxury Residential Villas & Gated Communities
- Commercial Office Complexes & IT Parks
- Educational Campuses & Institutional Buildings
- Hotels, Resorts & Heritage Properties
Plain Elevation Bricks — Advantages and Limitations
PERFORMANCE MATRIX
Key Advantages
- Only 15 mm thick — no load added to the structure
- Fixes with tile adhesive on existing walls
- Clean lines for modular and stack bond patterns
- Colour through the body, not a surface coat
ALL-WEATHER CERTIFIED
Indian Climate Suitability
Heavy Monsoon Proof 50°C+ UV Resilient Through-Body Color
Produced for Indian exterior exposure — heavy monsoon rainfall, intense summer temperatures reaching the high 40s°C, and severe UV radiation. Colour is through-body rather than surface-applied, ensuring weathering presents as an elegant architectural patina without coating delamination.
STRUCTURAL SPECIFICATION
Limitations & Engineering Limits
Designed specifically as non-load bearing facade cladding, solar screen louvers, or architectural partition masonry. Free-standing perimeter walls exceeding 3.0 meters in total height mandate structural steel or concrete column anchoring ties for wind load stability.
Mandatory: Use 6mm dowel ties every 3rd course on exterior screens.
Plain Elevation Bricks — Installation, Care and Maintenance
SITE EXECUTION MANUAL
Installation Guidance
01
Surface Preparation
Thoroughly clean and level the concrete base beam, lintel, or floor slab prior to first course alignment.
02
Mortar / Adhesive Specification
Use polymer-modified tile adhesive or 1:3 cement-sand mortar matrix maintaining a uniform 8-10mm joint spacing.
03
Alignment & Structural Reinforcement
Check vertical plumb with spirit level. Embed 6mm MS/SS dowel rods every 3rd course into adjacent structural columns for rigid anchoring.
FACILITY MANAGEMENT PROTOCOL
Care & Maintenance
Routine Surface Cleaning
Periodic low-pressure clean water spray is sufficient to remove ambient dust and environmental debris.
Hydrophobic Sealer Protection
Apply a transparent breathable silicone / fluoropolymer sealer every 5 years for enhanced exterior facade stain immunity.
Efflorescence Prevention
Our engineered mix design incorporates anti-efflorescence chemical complexes to neutralize surface salting.
Plain Elevation Bricks — Pricing, Packaging and Dispatch
COMMERCIAL MATRIX
Price Factors & Minimum Order Quantity
Minimum Order Quantity (MOQ)
200 sq.ft.
Final ex-factory project pricing is calculated based on total quantity volume, custom sizing dimensions, selected colour finish, and transit distance to your site PIN code. Institutional and commercial bulk orders qualify for Tier-1 direct factory pricing.
GST Invoice Included Volume Tier Discounts Direct Factory Rates
DISPATCH & LOGISTICS
Packaging & All-India Dispatch
Packaging Standard
Strapped heavy-duty ISPM-15 heat-treated wooden pallets with corrugated edge protectors, corner shock cushions, and heavy-gauge weatherproof shrink wrapping for 100% transit zero-damage safety.
Dispatch Schedule
Standard stock architectural products are dispatched within 48-72 hours. Bespoke CNC moulds and custom colour batch production dispatched within 7-10 working days via dedicated freight carriers across India.
Plain Elevation Bricks — Frequently Asked Questions
ARCHITECTURAL KNOWLEDGE BASE
Frequently Asked Questions
How is Plain Elevation Bricks delivered to site safely?
Products are securely palletized with corner impact protection, strapped with heavy-gauge PET banding, shrink-wrapped, and shipped directly to your project site via dedicated container logistics with door delivery support.
Can custom colors, textures, or sizes be fabricated for landmark developments?
Yes! Kamad Infratech specializes in bespoke CNC moulds, custom geometric patterns, and pantone-matched terracotta & precast pigments for architectural projects exceeding 1,000 sq.ft.
What is the structural performance warranty and material lifespan?
Our precast concrete and kiln-fired terracotta elements have an engineered design life of 50+ years. Every batch is supplied with certified lab test reports verifying compressive strength, water absorption, and zero manufacturing defects.
