Rajwadi Roofing Tile
Twin-roll Rajwadi profile with deep ribs and fast drainage.
✦ KEY ARCHITECTURAL HIGHLIGHTS
- Deep ribs drain heavy monsoon rain quickly
- Heavier section resists wind lift
- Traditional Rajwadi look on a modern roof
⚡ LIVE ESTIMATORProject Quantity & Freight Weight
Enter elevation wall area to calculate exact piece count & logistics tonnageSQ. FT.
Pieces Required
360pcs
Est. Weight
288.00 MT (288,000 kg)
ARCHITECTURAL SPECIFICATION & OVERVIEW
About Rajwadi Roofing Tile
Rajwadi Roofing Tile is part of the Roofing Tiles range manufactured by Kamad Infratech.
A twin-roll Rajasthani profile with deeper ribs, which throws a stronger shadow across the roof and drains faster in heavy rain.
Heavier than the Roman tile at 800 g a piece, and correspondingly more resistant to lifting in high wind.
Enterprise GradeEngineered for large-scale architectural projects
Climate ResilientTested for Indian climate extremes — heat, rain, humidity
Factory PrecisionBatch-controlled production with anti-efflorescence mix design
Sustainable MaterialEco-conscious production with minimal carbon footprint
Rajwadi Roofing Tile — Technical Specifications
Technical Specifications & Dimensional Matrix
Available Sizes & Dimensions
8 in × 5 in
Colours & Surface Finishes
TerracottaGreyBlackWhite
Material Composition
Pigmented concrete
Minimum Order Quantity (MOQ)
1,000 pieces
Rajwadi Roofing Tile — Applications and Usage Areas
Primary Applications
- Exterior Building Facades & Solar Shading Screens
- Ventilated Boundary Walls & Perimeter Enclosures
- Interior Feature Partition Walls & Atrium Screens
- Balcony & Terrace Privacy Screening
Usage Areas & Project Types
- Luxury Residential Villas & Gated Communities
- Commercial Office Complexes & IT Parks
- Educational Campuses & Institutional Buildings
- Hotels, Resorts & Heritage Properties
Rajwadi Roofing Tile — Advantages and Limitations
PERFORMANCE MATRIX
Key Advantages
- Deep ribs drain heavy monsoon rain quickly
- Heavier section resists wind lift
- Traditional Rajwadi look on a modern roof
ALL-WEATHER CERTIFIED
Indian Climate Suitability
Heavy Monsoon Proof 50°C+ UV Resilient Through-Body Color
Produced for Indian exterior exposure — heavy monsoon rainfall, intense summer temperatures reaching the high 40s°C, and severe UV radiation. Colour is through-body rather than surface-applied, ensuring weathering presents as an elegant architectural patina without coating delamination.
STRUCTURAL SPECIFICATION
Limitations & Engineering Limits
Designed specifically as non-load bearing facade cladding, solar screen louvers, or architectural partition masonry. Free-standing perimeter walls exceeding 3.0 meters in total height mandate structural steel or concrete column anchoring ties for wind load stability.
Mandatory: Use 6mm dowel ties every 3rd course on exterior screens.
Rajwadi Roofing Tile — Installation, Care and Maintenance
SITE EXECUTION MANUAL
Installation Guidance
01
Surface Preparation
Thoroughly clean and level the concrete base beam, lintel, or floor slab prior to first course alignment.
02
Mortar / Adhesive Specification
Use polymer-modified tile adhesive or 1:3 cement-sand mortar matrix maintaining a uniform 8-10mm joint spacing.
03
Alignment & Structural Reinforcement
Check vertical plumb with spirit level. Embed 6mm MS/SS dowel rods every 3rd course into adjacent structural columns for rigid anchoring.
FACILITY MANAGEMENT PROTOCOL
Care & Maintenance
Routine Surface Cleaning
Periodic low-pressure clean water spray is sufficient to remove ambient dust and environmental debris.
Hydrophobic Sealer Protection
Apply a transparent breathable silicone / fluoropolymer sealer every 5 years for enhanced exterior facade stain immunity.
Efflorescence Prevention
Our engineered mix design incorporates anti-efflorescence chemical complexes to neutralize surface salting.
Rajwadi Roofing Tile — Pricing, Packaging and Dispatch
COMMERCIAL MATRIX
Price Factors & Minimum Order Quantity
Minimum Order Quantity (MOQ)
1,000 pieces
Final ex-factory project pricing is calculated based on total quantity volume, custom sizing dimensions, selected colour finish, and transit distance to your site PIN code. Institutional and commercial bulk orders qualify for Tier-1 direct factory pricing.
GST Invoice Included Volume Tier Discounts Direct Factory Rates
DISPATCH & LOGISTICS
Packaging & All-India Dispatch
Packaging Standard
Strapped heavy-duty ISPM-15 heat-treated wooden pallets with corrugated edge protectors, corner shock cushions, and heavy-gauge weatherproof shrink wrapping for 100% transit zero-damage safety.
Dispatch Schedule
Standard stock architectural products are dispatched within 48-72 hours. Bespoke CNC moulds and custom colour batch production dispatched within 7-10 working days via dedicated freight carriers across India.
Rajwadi Roofing Tile — Frequently Asked Questions
ARCHITECTURAL KNOWLEDGE BASE
Frequently Asked Questions
How is Rajwadi Roofing Tile delivered to site safely?
Products are securely palletized with corner impact protection, strapped with heavy-gauge PET banding, shrink-wrapped, and shipped directly to your project site via dedicated container logistics with door delivery support.
Can custom colors, textures, or sizes be fabricated for landmark developments?
Yes! Kamad Infratech specializes in bespoke CNC moulds, custom geometric patterns, and pantone-matched terracotta & precast pigments for architectural projects exceeding 1,000 sq.ft.
What is the structural performance warranty and material lifespan?
Our precast concrete and kiln-fired terracotta elements have an engineered design life of 50+ years. Every batch is supplied with certified lab test reports verifying compressive strength, water absorption, and zero manufacturing defects.
